VMware NSX is the network virtualization platform for the Software-Defined Data Center (SDDC), which delivers networking and security entirely in software, abstracted from the underlying physical infrastructure. NetBrain can discover the networks based on VMware NSX-V (for vSphere) and visualize the NSX-V networks on dynamic maps.

Example: A Visualized Topology Map of an NSX-V Distributed Logical Router.

Follow the steps below to visualize your NSX-V network:

1.Discover NSX-V Network

2.Auto-Update NSX-V Data in NetBrain through Benchmark

3.View NSX-V Network Components

4.Apply Data View to Visualize More NSX-V Network Data
